5.3 Making the settings via the partner gateway
component
You can also make the settings for the DMX gateway component
also via a partner gateway component.
In this configuration mode, you as a "sender" can send a maximum
510 bytes, since 2 bytes are required for the configuration.
To make the settings:
◦ Set the rotary switch of the DMX gateway component to "0, 0, 0"
◦ Use the master software to configure the individual bits of the first 2
bytes of the DMX data.
They are assigned as follows:
Byt
e
Bit Function Setting options
0 0
(LSB)
Number
A 9-Bit value range can be set
here. The meaning of this value
differs depending on the mode.
"Sender" function mode
Number of channels to be
sent
: 1-510
Default value: 510
! Since the first two bytes are
occupied by the configura-
tion data, a maximum 510
bytes of DMX data can be
transmitted in sender mode.
"Receiver" function mode
Receiver address: 1-512
default value: 1
1
2
3
4
5
6
7
1 0
1
(MSB)
2 - -
3 - -
4 - -
5 Zero data
determine the behavior with a
communication interruption.
0= inactive
Last received data are re-
tained
1= active
After 1s communication in-
terruption, all data bytes are
set to 0
6 Mode 0= Sender
1= Receiver
7 Termination 0=Termination active
1= Termination inactive
