Instructions

DO0262R00-MGW-UM-DMX-EN 21 / 25
Value Switch setting
at the switch
Function mode
1 2 3
0 0 0 0 Configuration is via the partner gateway component
1 0 0 1 Receiver mode, bus termination inactive, start
address = 1
[…]
512 5 1 2 Receiver mode, bus termination inactive, start
address = 512
513 5 1 3 Sender mode, bus termination active, 512 bytes are
transmitted
[…]
999 9 9 9 Sender mode, bus termination active, 512 bytes are
transmitted
Restart the gateway component to activate new settings.
Examples:
Receiver mode, start address
73
To set a DMX receiver with inactive bus termination at start address
73, you must set the switch as follows:
SW_1 = 0
SW_2 = 7
SW_3 = 3
Sender mode
To set a DMX sender with activated bus termination, which transmits
512 channels, you must set the switch as follows:
SW_1 = 5
SW_2 = 1
SW_3 = 3
Partner gateway mode
To configure via a partner gateway, you must set the switch as
follows:
SW_1 = 0
SW_2 = 0
SW_3 = 0
Configuration
