4.6 Connecting a Gateway to the Fieldbus
To connect the gateway component to DMX, you need an adapter.
The table below shows an example connection to a 3-pole XLR plug.
Connection Function Pin assignment for
XLR plug
1 - -
2 - -
3 - -
4 Earth (screen) 1
5 DMX + 3
6 DMX - 2
7 - -
8 - -
