3.3 Status LEDs
The signals of the status LEDs for DMX have the following meaning:
LED
designation
Signal Meaning
Power off Gateway not running
flashes, green Initialization phase not yet completed
on, green All system components are functioning
perfectly
flashes, red Correctable error (e.g. second gateway
component missing)
on, red Serious error/defect in the gateway
Term on, green Bus termination not active
off Bus termination not active
Traffic green, flashes DMX data active (master and slave
mode)
red, on Slave mode: DMX data inactive
