Dishwasher Use & Care Manual Table of Contents Important Safety Instructions-------------------------2 Features of your new dishwasher-----------------3-4 Operating Instructions-------------------------------5-8 Preparing and loading dishes---------------------9-14 Care & cleaning-------------------------------------15-17 Troubleshooting------------------------------------18-19 1 FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.
Important safety instruction WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, and to prevent property damage, personal injury. Proper installation Please install your dishwasher properly follow the installation guide. Water supply temperature should be 120℉ or 149℉. Dispose of the discarded appliance and packing material properly. The dishwasher must be grounded, or it can result in a risk of electric shock.
Features of your new dishwasher Specification Capacity 14 place settings Dimension 23,8 x 25,5 x 33,7 in. (Wx D x H) Weight unpacked 94lb (42.
Features of your new dishwasher Features Filter System Your dishwasher has amultiple Filter the System there are four filter-meshes.Itcan separate soiled water and clean water in different chambers. The multiple filter system helps your dishwasher to get better performance with less water and less energy . Smart Wash System Your dishwasher has Smart Wash System. a partial load of lightly soiled dishes is placed in the unit,a wash cycle similar to a short wash will automatically be performed.
Getting Started How your dishwasher cleans 1.Load dishwasher (Seepreparing and loading dishes). 2.Add detergent (SeeFill detergent to the dispenser). 3.Add rinse aid,if needed (SeeFill rinse to dispenser). 4.Close door to latch. 5.Select desired CYCLE (SeeCycle Chart).The indicator light above the pad will glow when selected. 6.Select desired OPTIONS (SeeEnergy Options). The indicator light above the pad will glow when selected. 7.Run hot water faucet nearest dishwasher until water is hot.Turn water off.
ntrol panel Control 1 2 3 4 5 7 6 Wash Cycle Selections 9 This cycle is for hard-to-clean,heavily soiled dishes, and dishes. Normal wash 2 This cycle is for regularly soiled dinner dishes or silverware. China crystal 3 10 This cycle is for lightly soiled china and crystal. Rinse only 11 Child lock Votex wash Heated Dry When the” Heated Dry” function is selected, the heater will work during the drying process. ENERGY SAVER .
Operating dishwasher 17 18 19 14 15 16 Start/Cancel 16 14 Push door firmly door latches automatically. indicator Select the wash cycle and options light above the pad will turn on.To start pressthe light will wash Start/Cancel key action begins.To cancel when a cycle is running,press Start/Cancelpad once and the11dishwasher will start a 60 the end of the second drain and then shut can select the desired cycle.
Operating dishwasher Status Window NOTE The time remaining could suddenly increase or drop several minutes. Thismeans the Smart Sensor has checked the soil level and determined if additional water fills are needed or if water fills can be deleted. 01-24 If the Delay Start option is sel of hours shows in the Status the dishwasher is working and the wash cycle time is more of hours and minutes left shows than a alternately in the Status Window.
Adjustable Upper Rack The upper rack height can be easily adjusted to accommodate loading taller dishes in either rack. To accommodate taller dishes in the bottom rack, there are 2 positions available: Upper rack 1. Lift the rack for upper position Lower rack The upper rack in the upper position Dish Preparation Scrape away large pieces of food, bones, pits, toothpicks,etc.The continuous filtered wash system will remove the remaining food particles. Burned-on foods shouldbe loosened before loading.
Loading the Upper Rack Make sure the loaded dishes do not interfere with the rotation of the middle spray arm,which is located at the bottom of the upper rack.(Checkthis by rotating the middle spray arm by hand.) The upper rack is designed for cups,glasses,small plates,bowls and plastic items marked safe etc. For best results,place the bowls,cups,glasses,sauce pans with soiled surface facing down or toward the center.Tilt slightly for better drainage.
Cutlery Rack 8 place settings Cutlery Rack 12 place settings Cutlery Rack 14 place settings Upper Rack 8 place settings Upper Rack 12 place settings Upper Rack 14 place settings Bottom Rack 8 place settings Bottom Rack 12 place settings Bottom Rack 14 place settings 11 FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.
Preparing and loading dishes Adding A Dish CAUTION To add or remove items after wash cycle starts: 1 Open door slightly and wait a few seconds until wash action stops before completely opening. 2 Add the item. 3 Close door firmly to latch and cycle will automatically resume. TO AVOID BURN INJURY:Slightly open door and wait until spray arms and wash action stop.Hot water may splash out of dishwasher.Failure to do so may result in injury.
Preparing and loading dishes Filling the rinse aid dispenser Your dishwasher is designed to use a liquid rinse aid. Theuse of rinse greatly improves drying performance after the final rinse. Donot use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month, try to keep it full, but do not over fill. 1.Open the door,turn the dispenser cap to left and lift it out. 3.
Preparing and loading dishes 3.Close the dispenser cover The amount of the detergent needed depends on the cycle and soil level of dishes,refer to the table below and adjust the recommended amount as necessary for your load.
Cleaning the exterior door and panel 1. Stainless steel panel Clean the stainless steel door and handle regularly to remove the debris with cleaning soft cloth. Do not use appliance wax,polish,bleach or products containing chlorine to clean the stainless steel door. 2.Control panel Clean the control panel with a lightly dampened cloth,clean it gently .
Clean the Fine Filter Take out the Cylinder Filter and remove the Fine Filter from the dishwasher tub bottom. To remove the Fine Filter you must first remove the bottom spray arm as shown below. Flush the Fine Filter by holding it under running water and replace. 16 FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.
Clean the door gasket Air gap Clean the door gasket with a damp cloth to remove food particles regularly. If there is an air gap installed with your dishwasher, make sure it is clean so the dishwasher will drain properly. Air gap is not part of your dishwasher. Before you clean the air gap,turn off the dishwasher firstly and lift off the cover Remove the plastic cap and clean with a toothpick. Protect against freezing Inside The inside of the dishwasher is self-cleaningwith normal use.
Troubleshooting before calling for service Problem Dishwasher won't start Dishwasher beeps at the end of the cycle Rinse Aid light on Dishwasher operates too long Door may not be closed properly Shut the door completely make sure it is latched Power supply or power line is not connected Check and connect the power supply Delay Start option has been selected Refer Child Lock activated(selected models) Deactivate the child lock,refer to child lock section in this manual The rinse aid level is low
Troubleshooting Problem Solution Possible cause Detergent dispenser will not shut Improper operation of the detergent cover Add the detergent and rinse aid as indicated by the manual Water remains in the dishwasher Previous cycle has not finished orhas been interrupted Select the proper cycle as introduced by the manual Check the air gap if you have Make sure the disposer is empty if the dishwasher is connected to the disposer Drain is clogged Dishwasher does not drain properly Suds in the tub Di
