Brochure

SQ SERIES 2
Kubota SQ Series 2
ensure a much quieter,
more efficient, and
longer power supply.
BASE MOUNTED FUEL TANK
The SQ series is equipped with large capacity
bottom mounted fuel tank to prevent fuel spills
inside the enclosure (Bunded 110%). The locking
fuel door is placed to avoid damage and
simplify refuelling.
COMPACT AND EASILY TRANSPORTED
The advanced design and superior engineering
minimises both space and weight. Transportability
is improved with slots on each side of the machine
for safe forklift truck transportation.
LOCKING CONTROL PANEL DOOR
Shields instrument panel from the elements and
permits observation of all key functions without
opening the door.
DESIGNED WITH SAFETY IN MIND
In case of abnormal oil pressure/ water
temperature, or in case the fan belt breaks, the
emergency stop system will automatically shut
the unit down. With the emergency stop button
placed on the outside rather than on the inside,
it’s now possible to stop the unit in less time.
EASY ONE SIDE MAINTENANCE
Engine oil and coolant extensions are provided
to ease regularly scheduled maintenance.
Oil gauge, oil filter, oil replenishment port, fuel
filter, water reserve tank, battery and air cleaner
are all located on one side for quick inspection
and maintenance.
OVER- SIZED MUFFLER
Sound level has been lowered by the over
sized muffler.
ENCLOSURE WITH A NOISE
ABSORBING DUCT
Noise within the generator unit has been lowered
by improving the noise reduction enclosure and by
adding a new noise absorbing duct with
3 air intake holes.
QUIETER COOLING FAN
Kubota not only reduced fan related noise with
this larger-diameter, slower speed fan, but was
also able to maintain the same cooling effect
as one running at the normal speed.
NEW FEATURES
DIGITAL
CONTROL
PANEL
FUEL GAUGE
MAIN CIRCUIT
BREAKER
4 SWITCHES
4 RECEPTACLES
IP66
2 ADDITIONAL
SPACES
AUTO START CONTROLLER –
DIGITAL OPTION ONLY
+ Large back-lit icon LCD display:
The Deep Sea 4520 Auto Start
Controller has a large back lit screen
which clearly displays operator
information in an easy to read manner.
+ Added water proof recessed
button receptacles
+ New emergency stop button
+ Compliant with AS3000
Wiring Standard
+ Factory tested to AS33017
+ RCD for each outlet (RCBO on
single phase outlets)
ENGINE
+ Limit switch has been added to shut
down engine when dooor opens
+ Battery isolator has been added
+ A larger capacity fuel tank
(62L > 100L) which enables
24 hours run time
BODY
+ All components have been recessed
+ Single key entry door
+ The base has been strengthened
to improve mobility
EMERGENCY
STOP BUTTON
WATER PROOF
ENCLOSURE
INCREASED SKID RAIL
MATERIAL THICKNESS
TOW POINT
LIMIT SWITCH
STANDARD BATTERY
ISOLATOR & OPTIONAL
CHARGER
FUEL TANK
24 HOUR RUN TIME
(BUNDED 110%)
