Linear measuring technology
Technology in detail
Measuring length up to 5 m
integrated inclinometerDraw wire encoder C100
Draw wire mechanics
with redundant sensors
Inclinometer with option RC1
Setting possibility 360°
Redundant signals possible.
Setting possibilities:
· Switching between setting possibilities 180° and 360°.
· Switching between synchronous and asynchronous output.
· Change of direction of rotation (cw/ccw).
· Setting and resetting an offset.
Setting possibility ±180°
Dimensions
Dimensions in mm [inch]
1
4 x ø 4.4 [0.17]
