Linear measuring technology
Linear measuring technology
Measuring length up to 5 m
integrated inclinometerDraw wire encoder C100
Draw wire mechanics
with redundant sensors
Connection technology for analog sensor Order no.
Cordset, pre-assembled M12 female connector with coupling nut, 5-pin
2 m [6.56‘] PVC cable 05.00.6081.2211.002M
Connector, self-assembly (straight) M12 female connector with coupling nut, 5-pin 8.0000.5116.0000
Order code
with relais output
Order code
with switch output
D8. XXXX RL1 11 000
a b dc
. . .
a
Measuring length
0100 = 1 m
0200 = 2 m
0300 = 3 m
0400 = 4 m
0500 = 5 m
a
Measuring length
0100 = 1 m
0200 = 2 m
0300 = 3 m
0400 = 4 m
0500 = 5 m
b
Sensor type
RL1 = relay output
b
Sensor type
SW3 = 3 switch outputs
c
Type of connection
1 = M12 connector, 5-pin
d
Power supply
1 = 9 ... 30 V DC
c
Type of connection
4 = M12 connector, 12-pin
d
Power supply
1 = 9 ... 30 V DC
C100
Order code
with incremental output
D8. XXXX XXX 1X 000
a b dc
. . .
a
Measuring length
0100 = 1 m
0200 = 2 m
0300 = 3 m
0400 = 4 m
0500 = 5 m
b
Sensor type
I11 = incremental AB, 512 ppr
I12 = incremental ABZ, 512 ppr
I21 = incremental AB, 1024 ppr
I22 = incremental ABZ, 1024 ppr
c
Type of connection
1 = M12 connector, 5-pin
3 = radial cable, 2 m [6.56‘]
d
Output circuit / Power supply
1 = TTL / 9 ... 30 V DC
C100
D8. XXXX SW3 14 000
a b dc
. . .C100
Accessories relais output Order no.
Accessories switch output Order no.
Teach adapter (for sensor type RL1) M12 connector, 5-pin
adapter with button D8.C100.RL1.TEACH
Visualization adapter (for sensor type SW3) M12 connector, 12-pin D8.C100.SW3.VISUAL
