Instruction Manual

TECHNICAL DATA 6
25
BATCHFLUX 5500 C
www.krohne.com05/2014 - 4000827703 - HB BATCHFLUX 5500 R03 en
Electrical connections
Power supply 24 VDC ± 25%
Power consumption ≤ 3 W
Switch on current ≤ 5 A (< 100 μs) at 24 VDC
Voltage loss Possible for a maximum of 20 ms according to NAMUR NE21.
BATCHMON Plus For parameter setting and diagnostic purposes, communication via
PC with a single device (optional)
Status output Configurable; error, flow direction, on/off
Frequency output
Frequency outputFrequency output
Frequency output
Type Frequency (passive) / galvanically isolated from power supply
Function All operating data preset at factory.
Interval Counter gate time ≥ 1000 / (P
100%
[Hz])
Frequency output ≤ 10 kHz
Pulse width at full scale value ≤ 10 Hz: 50, 100, 200 or 500 ms
> 10 Hz: automatic, pulse width = 1 / (2 x f
100%
) or symmetrical, 1:1
Passive operation Connection of electronic or electromechanical counters.
External voltage: ≤ 30 VDC / ≤ 24 VAC
Load: I
max
≤ 20 mA
Low flow cut-off Threshold: 0...20%
Hysteresis: 0...20%
Hysteresis ≤ threshold
Depending on customers specifications.
Approvals and certifications
CE
CECE
CE
This device fulfills the statutory requirements of the EC directives.
The manufacturer certifies successful testing of the product by
applying the CE mark.
Electromagnetic compatibility Directive: 2004/108/EC
Harmonized standard: EN 61326-1: 2006
Low voltage directive Directive: 2006/95/EC
Harmonized standard: EN 61010: 2010
Pressure equipment directive Directive: 97/23/EC
Category SEP
Fluid group 1
Production module H
Other approvals and standards
Other approvals and standardsOther approvals and standards
Other approvals and standards
Protection category acc. to
IEC 529 / EN 60529
DN2.5...6 / DN25...40: IP 66/67
DN10...15: IP 69K
Shock test IEC 60068-2-27
Vibration test IEC 60068-2-64
Hygienic DN2.5...15: 3A
FDA approved materials
