6 TECHNICAL DATA
24
BATCHFLUX 5500 C
www.krohne.com 05/2014 - 4000827703 - HB BATCHFLUX 5500 R03 en
Operating conditions
Temperature
TemperatureTemperature
Temperature
Process temperature Dependent on ambient temperature. See chapter "Temperatures".
Cleaning temperature SIP: Maximum 1 hour at 150°C / +302°F
CIP: Maximum 1 hour at 140°C / +284°F
Shock ≤ 3K/s
Ambient temperature -40…+60°C/ -40…+140°F
Storage temperature -50…+70°C/ -58…+158°F
Pressure
PressurePressure
Pressure
Ambient Atmospheric
Process pressure up to 16 bar / 232 psi for DN10...15
up to 40 bar / 580 psi for DN2.5...6 / DN25...40
Vacuum load 0mbara / 0psig
Chemical properties
Chemical propertiesChemical properties
Chemical properties
Physical condition Liquids
Electrical conductivity ≥ 5 μS/cm (≥ 20 μS/cm for demineralised water)
Recommended flow velocity -12...+12 m/s / -39...+39 ft/s
Installation conditions
Installation For detailed information see chapter "Installation".
Inlet run ≥ 5 DN
Outlet run ≥ 2 DN
Dimensions and weights For detailed information see chapter "Dimensions and weights".
Materials
Sensor- and converter housing Stainless steel 1.4404 / 1.4408
Measuring tube Fused in-place
Measuring electrodes DN2.5...15: Cermet
DN25...40: Platinum
Process connections
Connection Sandwich design
Optional: Pressure relief groove at flange facing of the sensor
Construction drawings of recommenced counter flanges are
available from download centre.
