3.4 General requirements
INFORMATION!
The following precautions must be taken to ensure reliable installation.
• Make sure that there is adequate space to the sides.
• Protect the signal converter from direct sunlight and install a sun shade if necessary.
• Support the pipeline on both side of the flowmeter.
• Do not expose the signal converter to intense vibration. The flowmeters are tested for a
vibration level in accordance with IEC 60068-2-64.
Figure 3-1: Avoid vibrations
Figure 3-2: Avoid strong magnetic fileds
Figure 3-3: Horizontal piperun
CAUTION!
Install in a slightly descending pipe section to prevent air from collecting and to avoid faulty
measurements (meter can drain).
