I N S TA L L AT I O N MA N UA L Handmade Stainless Steel Undermount Kitchen Sink KHU100-30 / KHU100-32 / KHU101-23 / KHU102-33 / KHU103-33 / KHU104-33 / KHU105-32 / KHU121-23 / KHU122-23 / KHU123-32 www.kraususa.com I toll free: 1.800.775.0703 I © 2016 Kraus USA Inc.
Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help. For more information about Kraus products, please visit: www.kraususa.
Prior to Installation: • Make sure that you have all necessary parts by checking the parts list.
I Tools you will need: Phillips screwdriver Hex wrench Silicone Sealant Safety Goggles Drill Phillips Screwdriver Putty Knife Silicone Sealant Silicone Adhesive Jig Saw B Hex wrench Scissors Adjustable wrench Phillips screwdriver Tape Measure Pencil Screwdriver Tools You Will Need I J J F Adjustable wrench NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount sinks with countertop materials other than wood, marble, or granite D Parts List • Cut-Out Templ
17” 432mm 28” 711mm 19” 483mm 18” 457mm 16” 406mm Dimensions 30” 762mm 30” 762mm KHU100-30 30” x 18” x 10” Min Cabinet Size: 33” Matching Grid: KBG-100-30 Drain Model #: BST-1 10” 254mm 10” 254mm 32” 813mm 19” 483mm 17” 432mm 18” 457mm 16” 406mm KHU100-32 32” x 17” x 10” Min Cabinet Size: 36” Matching Grid: KBG-100-32 KHU102-33 Drain Model #: BST-1 21” 533mm 10” 254mm 10” 254mm 32-3/4” 832mm 10” 254mm KHU101-23 23” x 18” x 10” Min Cabinet Size: 27” Matching Grid: KBG-101-23 Drain Model
Dimensions KHU105-32 16-7/8” 429mm KHU123-32 10” 254mm 15” 381mm 15” 17” 381mm 432mm 17” 432mm 20” 508mm 20” 18” 508mm 457mm 18” 457mm KHU123-32 KHU105-32 30 1/2” x 18” x 10” Min Cabinet Size: 36” Matching Grid: KBG-105-32-1 and KBG-105-32-2 Drain Model #: BST-1 & ST-1 11” 279mm 18” 457mm 23” 584mm KHU122-23 23 3/4” x 18 3/4” x 10” Min Cabinet Size: 27” Matching Grid: KBG-122-23 Drain Model #: BST-1 10” 254mm 10” 254mm 10” 254mm 10” 254mm 32” 813mm 11” 279mm 32” 813mm 23-3/4” 603mm KHU121
DETERMINE REVEAL TYPE 1.
Step1 2.
Step2 3.
Step3 4.
Determine location for mounting brackets; space 3/8”POSITIVE 1/8”NEGATIVE ZERO Centerline 5. Set up Mounting Brackets • Turn countertop over and align sink with countertop. Decide location for mounting brackets • Mounting holes should be ½” from edge of sink Step5 1/2" (13mm) Step6 Step5 6.
7. Install Anchors Step6 • Insert anchors into drilled holes and lightly tap with a hammer until flush 1/2 Step7 8. Secure Sink to Countertop • Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop.
9. Attach Mounting Hardware • Attach mounting hardware to secure bowl.
Step9 10. Install Plumbing Fixtures • Connect drain to sink. Connect trap to drain.
Codes/Standards Applicable: HELP LINE Our customer service hours are Monday – Friday, 9am – 8pm EST. Be sure to visit our website at www.kraususa.com If you are a HOMEOWNER please contact a Kraus Customer Service Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a PLUMBING CONTRACTOR OR TRADE PROFESSIONAL please contact a Kraus Pro Representative at: Kraus USA, Inc.
