User manual

WP Frame (a 3 Slot frame is available in the U.S.; 2 and 4 Slot frames are available in Europe)
You can attach up to 3 of any of the passive devices. If attaching just 1 or 2 passive devices,
cover the empty space(s) with the removable panels that are included with the WP FRAME.
Six Frame Adapter for 19" 1U Rack
You can attach up to 6 of any of the passive devices to the 19" 1U Rack Adapter
VPM-2 XGA Line Driver Wall Plate
The VPM-2 wall plate has 3 removable panels designed into the product that can be replaced
with up to 3 passive devices. It is available in 2 sizes, one for the US market (21.1cm x 11.4cm
(8.31" x 4.49", W, D)) and one for the European market (18.2cm x 9.55cm (7.17" x 3.76", W, D)).
Wall Plate (WP) Series

Passive Wall Plate Devices:
WA-1, WA-2, WA-3, WV-2, WAS-1, WAV-1, WX-1
Passive Connection Modules:
WB45, WRR, W1145, W4545, WBB, WBR, WR45

