User Guide

VP-724xl Communication Protocol
47
Control
Type
Function
Param
(for Set)
Function
Description
Comment
3: Set
4: Get
5 0~2
Graphics Setting:
Color Format
0: Default
1: RGB
2: YUV
3: Set
4: Get
6 0~2 Video Setting: Color Format
0: Default
1: RGB
2: YUV
3: Set
4: Get
7 0~6
Video Setting: Video
Standard
0: Video Standard - Auto
1: Video Standard - NTSC
2: Video Standard - NTSC
4.43
3: Video Standard - PAL
4: Video Standard - PAL-N
5: Video Standard - PAL-M
6: Video Standard -
SECAM
3: Set
4: Get
8 0~1 Video Setting: Film Mode
0: Off
1: On
3: Set
4: Get
9 0~1
Audio Setting:
Stereo
0: Off
1: On
3: Set
4: Get
10 0~1 PIP Setting: PIP On/Off 0:Off, 1:On
3: Set
4: Get
11 0~9 PIP Setting: PIP Source
0: VGA-1
1: VGA-2 (VP-724 Only)
2: DVI
3: Component
4: YC-1
5: AV-1
6: YV-2
7: AV-2
8: Scart
9: TV
3: Set
4: Get
12 0~5 PIP Setting: PIP Size
0: 1/25
1: 1/16
2: 1/9
3: 1/4
4: Split
5: UserDefine
3: Set
4: Get
13 0~1 PIP Setting: PIP Frame
0: Off
1: On
3: Set
4: Get
14 0~2
Seamless Switch:
Mode
0: Fast
1: Moderate
2: Safe
3: Set
4: Get
15 0~2
Seamless Switch:
Background
0: Black
1: Blue
3: Set
4: Get
16 0~2
Seamless Switch:
Auto Search
0: Off
1: On
3: Set
4: Get
17 0~1 OSD Setting: Startup Logo
0: Off
1: On
3: Set
4: Get
18 0~1 OSD Setting: Size
0: Normal
1: Double
3: Set
4: Get
19 0~1 OSD Setting: Source Prompt
0: Off
1: On
3: Set
4: Get
20 0~1 OSD Setting: Blank Color
0: Blue
1: Black
