Table 2: Rear Panel Presentation Switcher / Scaler Features
# Feature Function
1 VIDEO OUT 1
HD15 Connector
Connects to the video acceptor (for example, a plasma display, projector or
monitor) that displays the scaled output
In the default HDTV mode, the signal goes out via 3 PINS: PIN 1 is P
r
, PIN 2
is Y, PIN 3 is P
b
2 VIDEO OUT 2
HD15 Connector
Connects to the video acceptor (for example, a plasma display, projector or
monitor) that displays the scaled output
In the default HDTV mode, the signal goes out via 3 PINS: PIN 1 is P
r
, PIN 2
is Y, PIN 3 P
b
3 AV1 Connects to the stereo audio input from composite video source 1
4 AV2 Connects to the stereo audio input from composite video source 2
5 YC1 Connects to the stereo audio input from s-Video source 1
6 YC2 Connects to the stereo audio input from s-Video source 2
7 COMP Connects to the stereo audio input from the component video source
8 DVI Connects to the stereo audio input from the DVI graphics source
9 VGA
1
1 Connects to the stereo audio input from the VGA graphics source 1
10
AUDIO IN
Terminal Block
Connectors
VGA
1
2 Connects to the stereo audio input from the VGA graphics source 2
11 LINE AUDIO OUT Terminal
Block Connector
Connects to the stereo audio acceptor
12 SPKR OUT
Terminal Block Connector
Connects to the speakers
13 DVI Connector Connects to the DVI (digital video interface) graphics source
14 VGA
1
1 HD15
Connector
Connects to the VGA (analog interface) graphics source 1. When
connecting an HDTV source, the signal goes in via 3 PINS: PIN 1 is Y, PIN
2 is Pb, and PIN 3 is Pr
15 VGA
1
2 HD15
Connector
Connects to the VGA (analog interface) graphics source 2. When
connecting an HDTV source, the signal goes in via 3 PINS: PIN 1 is Y, PIN
2 is Pb, and PIN 3 is Pr
16 Y RCA
Connector
17 Pb/Cb RCA
Connector
18
COMPONENT
Pr/Cr RCA
Connector
Connect to the component (Y, Pb/Cb, Pr/Cr) or RGB video source. If RGB
colorspace is used, connect as follows:
For video frequencies
2
, connect:
 Green to the Y connector
 Blue to the Pb/Cb connector
 Red to the Pr/Cr connector
For Graphics frequencies
3
, connect:
 Red to the Y connector
 Green to the Pb/Cb connector
 Blue to the Pr/Cr connector
19 YC2 4p Connector Connects to the s-Video source 2
20 AV2 RCA Connector Connects to the composite video source 2
21 YC1 4p Connector Connects to the s-Video source 1
22
VIDEO INPUTS
AV1 RCA Connector Connects to the composite video source 1
23 RS-232 DB 9 Connector Connects to PC or Serial Controller
24 Power Connector with Fuse AC connector enabling power supply to the unit
1 Only the VP-724xl has 2 VGA connectors. The VP-719xl, VP-720xl and VP-723xl have just 1 VGA connector
2 50Hz or 60Hz interlaced video
3 Including HD (480p, 576p, 720p and 1080i)
