16 VM-5ARII, VM-20ARII - Technical Specifications
VM-20ARII
INPUT:
4 video looping, 1Vpp/75Ω on BNC connectors with termination
switches; 4 audio stereo (or balanced mono) +4dBu/50kΩ, on
RCA connectors
OUTPUT:
Video: 20 (1:20, 2x1:10, 4x1:5, 1:10, 2x1:5) 1Vpp/75Ω on BNC
connectors; Audio: 20 (1:20, 2x1:10, 4x1:5, 1:10, 2x1:5) stereo or
balanced mono, +4dBu/50Ω, on RCA connectors
VIDEO BANDWIDTH (-3dB): 430MHz
AUDIO BANDWIDTH (-3dB): 110kHz
DIFF. GAIN: 0.06%
DIFF. PHASE: 0.08Deg
VIDEO S/N RATIO: 76dB
AUDIO S/N RATIO: 80dB
VIDEO CONTROL: -1.2/+1.7dB level, 0/+2.4dB EQ
AUDIO CONTROL: +0.3/+6.2dB
VIDEO COUPLING: DC/AC user selectable
AUDIO COUPLING: AC (input), DC (output)
AUDIO THD+NOISE: 0.02%
2nd HARMONIC: 0.002%
OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
POWER SOURCE: Universal switching power supply: 100-240 VAC, 50/60Hz 18.5VA
DIMENSIONS: 19” x 7” x 2U W, D, H, rack mountable
WEIGHT: 3.6kg (8lbs) approx
ACCESORIES: Power cord
Specifications are subject to change without notice at http://www.kramerelectronics.com
