VM-5ARII, VM-20ARII - Technical Specifications 15
7 Technical Specifications
VM-5ARII
INPUT: 1 video, composite or single component, looping,
1Vpp/75Ω on BNC connectors with termination switch;
1 audio stereo looping, +4dBu/50kΩ on RCA connectors
OUTPUT: 5 video, composite or single component, 1 Vpp/75Ω on
BNC connectors; 5 audio stereo, +4dBu/150Ω, on RCA
connectors
MAX. OUTPUT: Video: 2.2Vpp; Audio: 27Vpp
VIDEO BANDWIDTH (-3dB): 360MHz
AUDIO BANDWIDTH (-3dB): 60kHz
DIFF. GAIN: 0.03%
DIFF. PHASE: 0.06Deg
K-FACTOR: 0.05%
VIDEO S/N RATIO: 76dB
AUDIO S/N RATIO: 85dB
AUDIO THD: 0.021% (1V, 1kHz.)
CONTROL: Video gain: -1 to +1.8dB; audio gain: -40 to +6dB; EQ.: 0
to +2.5dB, audio: 0.2 to +6dB.
COUPLING: DC/AC selectable (video), AC (audio.)
OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
POWER SOURCE: 230V AC, 50/60Hz, (115V U.S.A.) 21VA.
DIMENSIONS: 19” x 7” x 1U W, D, H, rack mountable.
WEIGHT: 1.94kg (4.3lbs) approx.
ACCESORIES: Power cord.
Specifications are subject to change without notice at http://www.kramerelectronics.com
