5 Connecting the VP-300K 1:3 High Resolution UXGA DA
To connect your VP-300K 1:3 High Resolution UXGA DA
1
, as the example
in
Figure 4 illustrates, do the following
2
1. Connect a computer graphics source to the INPUT 15-pin HD connector.
:
2. Connect the OUTPUT 15-pin HD connectors to up to three
3
 Connect the OUTPUT 1 connector to acceptor 1 (for example, a
projector)
acceptors,
as follows:
 Connect the OUTPUT 2 connector to acceptor 2 (for example,
an LCD monitor)
 Connect the OUTPUT 3 connector to acceptor 3 (for example, a
display)
3. Connect the 5V DC power adapter (wall transformer) to the 5V DC socket
and connect the transformer to the mains electricity.
4. If required, set the:
 Hs and Vs switches
 ID Bit switch to ON
1 From this section on, all the information is relevant to the VP-200K, VP-300K and VP-400K, unless noted otherwise
2 Switch OFF the power on each device before connecting it to your VP-300K. After powering up your VP-300K, switch on
the power on each device
3 Two for the VP-200K and four for the VP-400K
