6 Technical Specifications
General
Band BSR100D VHF BSRU100D UHF
Frequency Range 136-174 MHz 410-510 MHz
Channel Bandwidth 12.5 KHz
Programming Fully PC programming
FCC Type Acceptance H78KPBSR100 H78KPBSRU100
ETSI 300.113
Operating Voltage 10-15 VDC
Current Consumption 150mA STBY; 3A TX 160mA STBY; 3A TX
Diagnostics Overload trouble, driver fault, timeout, PLL lock, dead
battery, power trouble, RSSI
Frequency Stability ± 2.5ppm @ -30 degrees Celsius to 60 degrees Celsius
(23 degrees Fahrenheit – 141degrees Fahrenheit)
Receiver
Sensitivity -117dBm @12 dB SINAD
Selectivity 65 dB for 12.5 KHz
Inter-modulation 75 dB
Spurious and Image
Rejection
75 dB
Transmitter
RF Output Power 1-10 Watts
Spurious Emission -80 dB
Modem
Data Rate 4800, 9600
Modulation DRCMSK
Bit Error Rate Better than 1 x 10
-5
@ 1.0µ V @ 4800 , 12.5 KHz
Signal Level EIA RS –232C
Data Format Asynchronous, serial, transparent
Word Length 7 or 8 bit words, 1 or 2 stop bits
Parity Even, odd, or none
Handshake RTS-CTS
RTS/CTS Delay 15 msec
Diagnostics Power, TX RX, internal temp
