CP930 Fast Ethernet Switch 26172.01.VC.031024/110113 Manual ID: 26683, Rev. Index 01 24 October, 2003 The product described in this manual is in compliance with all applied CE standards.
Preface CP930 Revision History Publication Title: CP930 Fast Ethernet Switch ID Number: 26683 Rev. Index 01 Brief Description of Changes Initial Issue Date of Issue 24 Oct, 2003 Imprint Kontron Modular Computers GmbH may be contacted via the following: MAILING ADDRESS TELEPHONE AND EMAIL Kontron Modular Computers GmbH Sudetenstrasse 7 D - 87600 Kaufbeuren Germany +49 (0) 800-SALESKONTRON sales@kontron.
CP930 Preface Table of Contents Revision History ........................................................................................................ ii Imprint ....................................................................................................................... ii Copyright ................................................................................................................... ii Table of Contents ...........................................................................
Preface CP930 Chapter 2. 2 Functional Description ................................................................................ 2 - 3 2.1 General Information ............................................................................... 2 - 3 2.1.1 Signal Conditioning ....................................................................... 2 - 3 2.1.2 Fast Ethernet Switch Controller .................................................... 2 - 3 2.1.3 System Interfaces .............................
CP930 Chapter 4. Preface 4 Configuration .............................................................................................. 4 - 3 ID 26683, Rev.
Preface CP930 This page was intentionally left blank. Page vi © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Preface List of Tables 1-1 CP930 Product Overview ......................................................................... 1 - 4 1-2 CP930 Main Specifications ...................................................................... 1 - 8 1-3 CP930 Power Consumption ..................................................................... 1 - 8 1-4 Applied Standards .................................................................................... 1 - 9 1-5 Related Publications ................
Preface CP930 This page was intentionally left blank. Page viii © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Preface List of Figures 1-1 CP930 Front Panel Standard Variant Views ............................................ 1 - 6 1-2 CP930 Board Layout ................................................................................ 1 - 7 2-1 CP930 Board Level Interfacing ................................................................ 2 - 5 2-2 CON3/4 and CON6 Connectors ............................................................... 2 - 6 2-3 CON5 Fiber Optic Receptacle, Front Panel View .........
Preface CP930 This page was intentionally left blank. Page x © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Preface Proprietary Note This document contains information proprietary to Kontron Modular Computers GmbH. It may not be copied or transmitted by any means, disclosed to others, or stored in any retrieval system or media without the prior written consent of Kontron Modular Computers GmbH or one of its authorized agents. The information contained in this document is, to the best of our knowledge, entirely correct.
Preface CP930 Explanation of Symbols CE Conformity This symbol indicates that the product described in this manual is in compliance with all applied CE standards. Please refer also to the section “Applied Standards” in this manual. Caution, Electric Shock! This symbol and title warn of hazards due to electrical shocks (> 60V) when touching products or parts of them.
CP930 Preface For Your Safety Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Preface CP930 General Instructions on Usage In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or modifications to the device, which are not explicitly approved by Kontron Modular Computers GmbH and described in this manual or received from Kontron’s Technical Support as a special handling instruction, will void your warranty.
CP930 Preface Two Year Warranty Kontron Modular Computers GmbH grants the original purchaser of Kontron’s products a TWO YEAR LIMITED HARDWARE WARRANTY as described in the following. However, no other warranties that may be granted or implied by anyone on behalf of Kontron are valid unless the consumer has the express written consent of Kontron Modular Computers GmbH.
Preface CP930 26172.01.VC.031024/110116 This page has been intentionally left blank. Page xvi © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Introduction Chapter 1 Introduction ID 26683, Rev.
Introduction CP930 This page was intentionally left blank. Page 1 - 2 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Introduction 1. Introduction 1.1 System Overview The CompactPCI board described in this manual operates with the PCI bus architecture to support additional I/O and memory-mapped devices as required by various industrial applications. For detailed information concerning the CompactPCI standard, please consult the complete Peripheral Component Interconnect (PCI) and CompactPCI Specifications.
Introduction 1.2 CP930 Product Overview The CP930 Five Channel Unmanaged Ethernet Switch is part of a comprehensive concept to provide CompactPCI system integrators with a complete range of CompactPCI communications products for data networks. This concept ensures a maximum degree of system design flexibility, thus allowing efficient and effective use of available resources. The function of this board is to provide applications with up to five Fast Ethernet interfaces.
CP930 Introduction 1.3 Board Overview 1.3.1 Board Introduction The CP930 five Channel Ethernet Switch is a 3U/4HP CPCI Board designed for use in a CPCI system. The CP930 itself is equipped with a five channel switch controller (Marvell 88E6063-RCJ). Network interfacing is accomplished using CAT5 UTP cabling for 10Base-T and 100Base-TX, and, optionally, for the fiber optical port, a MT-RJ multimode optical cable is recommended.
Introduction 1.4.2 CP930 Front Panels There are four standard variants of the CP930 available: • • • • Variant A: five front panel RJ45 connector and optionally extended temperatures Variant B: four front panel RJ45 connectors and one internal RJ45 connector Variant C: four RJ45 connectors; one MTRJ-type fiber optic connector, all on front panel Variant D: five front panel RJ45 connectors for mounting in a 3.
CP930 1.4.3 Introduction Board Layout The following figure shows the board layout for the above indicated variants of the CP930. Figure 1-2: CP930 Board Layout MAGNETICS VOLTAGE REGULATORS OSCILLATOR CON3 ETHERNET CONNECTOR CON5 CON4 ID 26683, Rev.
Introduction 1.5 CP930 Technical Specifications Table 1-2: CP930 Main Specifications GROUP CONTROLLER TYPE DESCRIPTION Marvell Ethernet Switch controller 88E6063-RCJ • Provides up to five channels Fast Ethernet including PHY • Ethernet standards supported: 10Base-T, 100Base-TX, 100Base-FX Ethernet copper Up to five, 8-contact, female, RJ45 connector(s) Supports up to five channels of full or half duplex 10Base-T, 100Base-TX Ethernet operation up to 100 meters cable length.
CP930 1.6 Introduction Applied Standards The CP930 complies with the requirements of the following standards: Table 1-4: Applied Standards TYPE CE MECHANICAL ENVIRONMENTAL TESTS 1.7 STANDARD Emission EN50081-1 Immunity, Industrial Environment EN50082-2 Immunity, IT Equipment EN55024 Electrical Safety EN60950 Mechanical Dimensions Conforms with IEEE1101.
Introduction CP930 This page was intentionally left blank. Page 1 - 10 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Functional Description Chapter 2 Functional Description ID 26683, Rev.
Functional Description CP930 This page was intentionally left blank. Page 2 - 2 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 2. Functional Description Functional Description The following chapters present more detailed, board level information about the CP930 5-Channel Fast Ethernet Switch whereby the board components and their basic functionality are discussed in general. 2.
Functional Description 2.1.3 CP930 System Interfaces The CP930 provides interfacing capability for the following system elements: • Up to 5 Fast Ethernet interfaces • Power supply Ethernet interfacing is achieved either via the CON3(RJ45), CON4(RJ45), CON5(FX), or CON6(RJ45) connectors depending on the CP930 variant in use and the type of network link: copper or fiber optic.
CP930 Functional Description Figure 2-1: CP930 Board Level Interfacing CP930 * Fast Ethernet Switch Controller 88E6063-RCJ Switch Controller on Chip and Frame Buffers MAC1 MAC2 MAC3 MAC4 PHY T/TX PHY T/TX PHY T/TX PHY T/TX Ch 2 * Ch 3 Ch 4 Ch 5 * MAC5 PHY T/TX/FX Ch 1 GALV. ISOL. GALV. ISOL. GALV. ISOL. GALV. ISOL. GALV. T/RFO ISOL.
Functional Description CP930 2.3 System Interfaces 2.3.1 Ethernet Wire Cabling Interface The Ethernet wire cabling interface is implemented using up to five 8-contact, female, RJ45 connectors. CON3 is implemented as channel 1-4, and CON4 is implemented as channel 5 when installed, this numbering being the front panel numbering and not the numbering of the channels from the chip.
CP930 2.3.2 Functional Description Channel 5 Interface Their are three variants of channel 5. One variant employs a standard Ethernet interface (RJ45) on the front panel, the second variant has a standard Ethernet RJ45 connector onboard, and the third variant has a duplex MT-RJ-type connector receptacle for interfacing to fiber optic links on the front panel. This variant is described below. 2.3.2.
Functional Description 2.3.3 CP930 CompactPCI Interface The CompactPCI interface is based on the specification PICMG 2.0 R 3.0, 10/1/99. The following figure and table indicate the pin layout and pinout of the CompactPCI connector, CON1 (J1).
CP930 2.3.4 Functional Description MOLEX Power Interface CON2 This connector is used for connecting the ATX power supply. Figure 2-5: MOLEX Power Interface CON2 Table 2-3: MOLEX Power Interface Pinout Pin 1 2 Signal 1 NC 2 GND 3 GND 4 5V 3 4 2.4 Monitor and Control (M/C) Monitor and Control functions are divided essentially into Pre-operation and Operation. Pre-operation M/C deals with board configuration and system requirements. Operation M/C covers direct operator interfaces. 2.4.
Functional Description CP930 This page was intentionally left blank. Page 2 - 10 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Installation Chapter 3 Installation ID 26683, Rev.
Installation CP930 This page was intentionally left blank. Page 3 - 2 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 3. Installation Installation The CP930 has been designed for easy installation. However, the following standard precautions, installation procedures and general information must be observed to ensure proper installation and to preclude damage to the board or injury to personnel. 3.1 Hardware Installation The product described in this manual can be installed in any available 3U slot of a CompactPCI system except for the system master slot. 3.1.
Installation 3.1.2 CP930 Installation Procedures for use in CompactPCI Slot To install the board proceed as follows: 1. Ensure that the safety requirements indicated above are observed (no Hotswap). Warning! Failure to comply with the instruction below may cause damage to the board or result in improper system operation. 2. Ensure that the board is properly configured for operation before installing. Note...
CP930 3.1.4 Installation Installation Procedures for Use in Floppy Disk Drive Slot To install the board proceed as follows: 1. Ensure that the safety requirements indicated above are observed (no Hotswap). Warning! Failure to comply with the instruction below may cause damage to the board or result in improper system operation. 2. Ensure that the board is properly configured for operation before installing. Note...
Installation CP930 This page was intentionally left blank. Page 3 - 6 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 Configuration Chapter 4 Configuration ID 26683, Rev.
Configuration CP930 This page was intentionally left blank. Page 4 - 2 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
CP930 4. Configuration Configuration The CP930 is designed for plug and play operation, and, as such, it does not have any user configurable board settings which are required for operation. ID 26683, Rev.
Configuration CP930 This page was intentionally left blank. Page 4 - 4 © 2003 Kontron Modular Computers GmbH ID 26683, Rev.
