26
Chapter
2
File
Menu
9i
910
900
700
300
File – Save – Elements [Ctrl] + [S]
Saving Element Data
This command is used to save the data selected in the element list. The data will be saved under the current
element le name.
Operating Procedure
1
From the element list, select the
element(s) to be saved.
M
emo
It is possible to select two or more elements by clicking
them while holding down the [Shift] or [Ctrl] key.
2
From the [File] menu, select [Save] and
then click [Elements].
The selected element data will be saved under
the current le name.
• If the selected elements are newly created ele-
ments or those that are loaded in another le for-
mat, the same dialog box as the one that appears
when the File – Save as – Elements command
is selected will appear, displaying the element
names in the order they are selected.
q If you want to change the le name, change it
and click the [Save] button.
• The rst element will be saved, and a dialog
box for the next element will appear.
• If you click the [Cancel] button, the next ele-
ment and subsequent elements will not be
saved.
Ref.
For details of the File – Save as – Elements com-
mand, refer to page 28.
