255
Chapter
2
Pop-up Menus
in Image Window
9i
910
900
700
300
Zoom Out
Reducing the Color Image
This command is used to reduce the currently displayed color image.
Operating Procedure
1
From the pop-up menu, click [Zoom
Out].
The color image will be reduced in steps by
the following magnication ratio each time this
command is selected.
1/12, 1/8, 1/6, 1/4, 1/3, 1/2, 2/3, 1, 2, 3, 4, 5, 6,
7 and 8
Actual Pixels
Displaying the Color Image in One-to-One Pixel Mode
This command is used to display color images in one-to-one pixel mode (one data pixel = one monitor pixel).
Operating Procedure
1
From the pop-up menu, click [Actual
Pixels].
The color images will be displayed in one-to-
one pixel mode.
Close
Changing the Color Image
This command is used to close the currently displayed color image.
Operating Procedure
1
From the pop-up menu, click [Close].
The color image will close.
