250
Chapter
2
Pop-up Menus
in Element List
9i
910
900
700
300
Show Element/Hide Element
Showing/Hiding Elements
This command is used to show or hide the element(s) selected in the element list.
M
emo
This command has the same effect as when a check mark is placed for the desired elements in the element list.
Note
Ifapop-upmenuisdisplayedinareasotherthanelementnameareaintheelementlist,themenuitems[ShowElement]
and[HideElement]willnotbedisplayed.
[Operating Procedure When Elements are Currently Hidden
1
Click the element(s) to be shown with
the right mouse button, and select
[Show Element] from the pop-up menu
that appears.
The element(s) will be shown.
Delete Elements
Deleting Elements from the Element List
This command is used to delete the element(s) selected from the element list.
M
emo
The Delete Elements command has the same function as the File – Remove Elements and Edit – Delete – Elements command.
Ref.
• For details of the File–RemoveElements command, refer to page 141.
• For details of the Edit–Delete–Elementscommand, refer to page 169.
Operating Procedure
1
Click the element(s) to be deleted with
the right mouse button, and select [De-
lete Elements] from the pop-up menu
that appears.
A message asking you whether to delete all
the selected elements will appear.
M
emo
If two or more elements have been selected by clicking
them while holding down the [Shift] or [Ctrl] key, they
can be deleted.
2
Click the [OK] button.
All the selected elements and their corre-
sponding points will be removed.
[Operating Procedure] When Elements are Currently Shown
1
Click the desired element(s) to be hid-
den with the right mouse button, and
select [Hide Element] from the pop-up
menu that appears.
The element(s) will be hidden.
