246
Chapter
2
9i
910
900
700
300
Pop-up Menus
in Element View
Window
Select element from window
Changing Displayed Element by Windows
This command is used to switch the currently selected element to another. This is possible only for the win-
dow in which a pop-up menu is displayed.
Note
Forthoseelementssetintheelementlisttobehidden,itisnotpossibletosetthemtobeshownbycheckingthe[Select]
checkbox.
Operating Procedure
1
From the pop-up menu, click [Select
element from window].
The [Element to be shown] dialog will appear.
• If all the elements are set to be shown (i.e. not set
to “Selective”), the dialog box will appear with
the [Select] checkbox unchecked.
Otherwise, the dialog box will appear with the
[Select] checkbox checked.
2
Check the [Select] checkbox (i.e. a
check mark is placed).
This allows you to set whether to show or hide
elements.
3
Check the checkbox of the desired ele-
ments to be shown.
4
Click the [OK] button.
The dialog box will close and the selected ele-
ments will be displayed.
“Selective” will appear in the window’s title
bar.
