Window – Tiling
Tiling Element View Windows
This command is used to tile all the currently displayed windows.
Window – Layout – 1/4
Displaying an Element View Windows in 1/4 Layout
This command is used display windows in 1/4 layout.
Window – Layout – 1/1
Displaying an Element View Window in 1/1 Layout
This command is used to fully display a window in the element view window area.
Operating Procedure
1
Click [Tiling] on the [Window] menu.
The currently displayed windows will be fully
tiled in the element view window area.
Operating Procedure
1
From the [Window] menu, select [Lay-
out] and then click [1/4].
Four views will appear, with Top view in the
top left, Isometric view in the top right, Front
view in the bottom left and Right view in the
bottom right.
Operating Procedure
1
From the [Window] menu, select [Lay-
out] and then click [1/1].
The active window will be maximized and dis-
played fully in the element view window area.
