204
Chapter
2
Build
Menu
9i
910
900
700
300
Build – Smooth – Element
Smoothing the Selected Element
This command is used to make the selected element smooth as well as to regularize surface points density.
Operating Procedure
1
From the element list, select one desired
element.
2
From the [Build] menu, select [Smooth]
and then click [Element].
The [Build-Smooth-Element] dialog box will
appear.
• The selected element will be ready to be dis-
played in all windows. It will be displayed if
it is not displayed in the active window or the
windows for which all the elements are set to be
displayed.
3
Set the parameters.
4
Click the [Apply] button.
The selected element will be smoothed ac-
cording to the parameter settings and then
displayed.
Parameters for [Build-Smooth-Element] Dialog Box
Weight
Used to set level of regularization of surface points density.
Repetition
Used to set level of smoothness.
• If you change the parameter settings and click
the [Apply] button again, the element will be
smoothed according to the new parameter set-
tings.
5
Click the [OK] button.
This will conrm execution of smoothing and
close the dialog box.
