198
Chapter
2
Build
Menu
9i
910
900
700
300
Build – Rotate – Elements
[R] (Effective while held down)
Rotating Element(s)
This command is used to rotate the selected element(s).
Left : Rotates the element(s) using the mouse.
Middle ([Shift] + Left) : Rotates the element(s) along the major axis.
Right : Rotates the element(s) by entering values.
Operating Procedure
1
From the element list, select the desired
element(s).
2
From the [Build] menu, select [Rotate]
and then click [Elements].
The selected element will be ready to be dis-
played in all windows. It will be displayed if it
is not displayed in the active window or the
windows for which all the elements are set to
be displayed.
3
Drag while holding down the left button.
The element(s) will rotate at their center of
gravity.
• Dragging with the middle (or [Shift] + Left)
button will rotate the element(s) along the major
axis.
M
emo
The element will be displayed in simple form during drag.
It will be displayed in detailed form when dragging is
canceled.
4
Press the [ESC] key.
Build – Rotate – Elements mode will be can-
celed.
