170
Chapter
2
Edit
Menu
9i
910
900
700
300
Edit – Delete – Points
[Ctrl] + [X]
Deleting the Selected Points
This command is used to delete the point(s) selected for the currently displayed element.
Note
Executionofthiscommandmaynotdisplaysimplieddata.
Operating Procedure
1
From the element list, select the desired
element.
Edit – Delete – Polygons
Deleting Polygons Comprised of Selected Points
This command is used to delete the polygon(s) that are comprised of the points selected in the currently displayed
element.
Operating Procedure
1
From the element list, select the desired
element.
M
emo
It is possible to select two or more elements by clicking
them while holding down the [Shift] or [Ctrl] key.
2
Select the point(s) you want to delete.
3
From the [Edit] menu, select [Delete]
and then click [Points].
The selected point(s) will be deleted.
• The selected element will be ready to be dis-
played in all windows. It will be displayed if
it is not displayed in the active window or the
windows for which all the elements are set to be
displayed.
M
emo
If all the points of the element are deleted, the element
will be deleted from the element list.
M
emo
It is possible to select two or more elements by clicking
them while holding down the [Shift] or [Ctrl] key.
2
Select the polygon(s) you want to de-
lete.
To select a polygon, all the constituent verti-
ces must be selected.
3
From the [Edit] menu, select [Delete]
and then click [Polygons].
The selected polygon(s) will be deleted.
• The selected element will be ready to be displayed
in all windows. It will be displayed if it is not dis-
played in the active window or the windows for
which all the elements are set to be displayed.
M
emo
Even if a polygon is deleted, the vertices comprising that
polygon will not be deleted.
