112
Chapter
2
File
Menu
700
File – Import – Digitizer – PC Card (When VIVID 700 is Selected)
n Sorting the Files (Sort radio button)
The [Name] and [Date] radio buttons are used to select whether le names are displayed alphabetically or
by date.
Operating Procedure
Before starting the following procedure, make sure that the [File-Import-Digitizer-PC Card] dialog box is
displayed.
1
Click the [Name] radio button to sort
the files alphabetically or [Date] radio
button to sort by date.
The les will be sorted alphabetically if the
[Name] radio button is selected or by date if
the [Date] radio button is selected.
• When sort is complete, selection state of each le
in the le list and preview image will be cleared.
n Updating the File List ([Update] button)
The [Update] button is used to load the le names from the memory card to this software and update the
le list. If the memory card is replaced while the [File-Import-Digitizer-PC Card] dialog box is open, be
sure to click this button to update the le list.
Operating Procedure
Before starting the following procedure, make sure that the [File-Import-Digitizer-PC Card] dialog box is
displayed.
1
Click the [Update] button.
All the le names in the memory card will be
loadedto the software and a new le list will be
displayed.
