100
Chapter
2
File
Menu
900
910
File – Import – Digitizer – PC Card (When VIVID 900/910 is Selected)
n Deleting All the Files ([Delete All] button)
The [Delete All] button is used to delete all the les from the memory card.
Operating Procedure
Before starting the following procedure, make sure that the [File-Import-Digitizer-PC Card] dialog box is
displayed.
1
Click the [Delete All] button.
A message dialog box will appear.
2
Click the [Delete All] button.
All the les in the memory card will be deleted.
Note
Allthelesinthememorycardwillbedeleted,irrespec-
tiveofwhetherornottheyarecurrentlyselectedinthe
lelist.
n Saving the Selected File ([Copy] button)
The [Copy] button is used to copy the selected le from the memory card and save it as camera data.
Operating Procedure
Before starting the following procedure, make sure that the [File-Import-Digitizer-PC Card] dialog box is
displayed.
1
From the file list, select the name of the
file you want to save.
2
Click the [Copy] button.
The [PC Card-Copy] dialog box will appear.
The copy destination directory and names of
the les present in that directory will be dis-
played.
3
Change the directory and file name if
necessary.
Note
Thelenamemustconsistofalphanumericcharacters
only.
4
Click the [Save] button.
All the les will be saved as camera data.
