Specifications

Technical Information
Cutout for recess-mount installations:
18-1/2″ (470 mm) width x 28-1/4″ (718 mm) height x
3-11/16″ (94 mm) depth
Installation Notes
Install this product according to the installation guide.
CAUTION: Risk of electric shock. Electrical
wiring may need to be relocated.
IMPORTANT! For recess mounting, the wall cavity must be
framed and cabinet secured to framing studs. Reroute any
electrical wires or water supply piping from the wall cavity. If
you encounter drain or vent piping, or if your wall is
load-bearing, consult a professional before proceeding.
CAUTION: Risk of property damage. For surface
mounting, use anchors (not provided) rated for the
loaded weight of this product. Refer to the anchor
manufacturer’s instructions.
When determining the height of the cabinet, ensure the
mirrored door will clear all obstacles (such as a faucet). A
minimum distance of 3″ (76 mm) is required.
This cabinet is designed for either right or left door swing.
Check for obstructions.
30"
(762 mm)
30"
(762 mm)
18-3/8"
(467 mm)
20"
(508 mm)
108˚
Wall
Surface
28-1/8"
(714 mm)
4-3/4" (121 mm)
1-1/4"
(32 mm)
3-9/16"
(90 mm)
5-3/4"
(146 mm)
Product Diagram
VERDERATM
VERDERATM MIRRORED CABINET
Page2of2
1212278-4-
A
