Operation Manual

17
English
Processing guide
Caution
The continuous operation time must not
exceed the processing guide below.
700 ml measuring cup
Food Max.
weight
Time
(sec)
Food
Preparation
Carrot 100 g 12 1 - 2 cm
Onions *
1
100 g 4-8 1 - 2 cm
Compote 80 g 8 /
Garlic 80 g 4-8 /
Cheese 50 g 12 1 - 2 cm
Eggs 3 yolks 4-8 Boiled
Ham 70 g 10 Sliced
Liquid *
2
400 ml 120 /
*
1
Onions: Peeled
*
2
Liquid: Soup, milk, water, etc.
Cleaning and care
Warning
Before cleaning, always switch o the
appliance and disconnect the plug from
power.
10
Cleaning the motor unit: Use a soft,
slightly damp cloth.
Warning
Make sure that no moisture is entering the
appliance during cleaning.
Never immerse the motor unit in water or
other liquids.
11
Cleaning the measuring cup and mat:
Use warm water and a mild cleaning agent.
12
Cleaning the hand blender
&
attachment: Wash the blending bar
13
under running water. Make sure that
no liquid enters the hollow shaft. Dry
thoroughly.
• Wash all other parts in warm soapy water,
then rinse and dry thoroughly.
• Never use corrosive detergents, wire
brushes, abrasive scourers, metal or sharp
implements to clean your appliance.
• Dry the appliance thoroughly after cleaning.
• Store the appliance in a cool, dry location,
away from children and pets.
Disposal
The crossed-out wheeled bin logo
requires the separate collection
of waste electric and electronic
equipment (WEEE). Electric and
electronic equipment may contain dangerous
and hazardous substances. Do not dispose of
this appliance as unsorted municipal waste.
Return it to a designated collection point for
the recycling of WEEE. By doing so, you will
help to conserve resources and protect the
environment. Contact your retailer or local
authorities for more information.
Blending
Suitable for: Blending juices and shakes,
mixing soft ingredients, pureeing cooked
ingredients.
2
Mount the motor unit on the hand blender.
3
To do so, align the motor unit’s icon with
the blender’s icon.
4
Rotate the blender in a clockwise direction
until it clicks in place (now and icons
are aligned).
5
Connect the plug to a suitable outlet.
6
Fill foodstu into the measuring cup.
Observe the maximum marking on the
measuring cup.
Dip the blender bar as deeply as possible
into the ingredients. Work through the
ingredients by moving the appliance gently
up and down.
Hold the blender vertically. Tilting it might
lead to splashing foodstu.
7
Set the desired speed selection. Press and
hold speed button I. Turbo can be achieved
by pressing and holding speed button II.
8
After use: Release the speed button and
disconnect the plug.
9
The anti-skid mat can be taken out as a lid
to cover the measuring cup and store inside
the fridge.
