ASSEMBLY INSTRUCTIONS

To avoid injury, adjust the auxiliary handle for optimum control and balance. Do not overreach when

operating grass trimmer/edger. Keep proper balance at all times for better control of the tool in

unexpected situations

2. Front handle

a. Position the front/auxiliary handle (E) onto the

upper portion of the trimmer section by sliding over

the upper tube (J).

b. Once the front handle is in the desired position,

place the fastening clamp (CC) on the underside

of the handle and secure in place by tightening

the fastening knob (BB). Tighten until there is no

movement in the handle.

c. The front handle can be adjusted to a suitable

position.

3. Connect upper/lower trimmer tubes

Slide the coupler (F) up the lower tube (K) and

engage the threads from the upper tube (J), rotate the

coupler (F) to the right to securely tighten.

WARNING
