ITEM # 0538510 3 DRAWER WORKBENCH MODEL #3DSSWM2013 Français p. 16 KOBALT® and the K Design® are registered trademarks of LF, LLC. All Rights Reserved. Español p. 31 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
TABLE OF CONTENTS Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Hardware Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . .
PACKAGE CONTENTS 24L 23L 25 24R 26R 31 29 30 27 28 5R 1L 32 14 3 13 8L 7 10 2L 33 9R 6R 12 4 4 11 17 15L 19 16R 18 16R 15L 20 15L 18 21 22 PART 1L 2L 3 4 5R 6R 7 8L 9R 10 11 12 13 14 15L 16R 17 DESCRIPTION Rear leg (left) Front leg (left) Side panel (left) Side frames (left & right) Rear leg (right) Front leg (right) Side panel (right) Drawer slide panel (left) Drawer slide panel (right) Slide support (intermediate) Bottom frame (front & rear) Base panel Upper panel Back panel Drawer
HARDWARE CONTENTS (shown actual size) AA M6x10 mm Screw Qty. 60 BB M4x6 mm Screw Qty. 44 CC M4x8 mm Screw Qty. 2 DD M3.2x5 mm Screw Qty. 12 EE M6x10 mm Screw Qty. 12 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. DANGER: ELECTRICAL SHOCK HAZARD. Do not plug the cord into an outlet with wet hands. Do not use this tool chest near a bathtub, shower or swimming pool. Follow this manual for recommended usage.
ASSEMBLY INSTRUCTIONS Important: Do not overtighten the screws as this may result in stripping them. After the workbench is completely assembled, fully tighten each screw. 1. Attach the left rear leg (1L) and the left front leg (2L) to a side frame (4) using screws (AA). On the side frame (4), ensure the edge with the hole is facing up. 1 1L Hardware Used 2L AA M6x10 mm Screw x4 AA 4 2. Attach the left side panel (3) using screws (AA).
ASSEMBLY INSTRUCTIONS 3. Align the left drawer slide panel (8L) with the predrilled holes, ensuring the slides are toward the front of the unit. Attach using screws (AA). 3 Hardware Used EE 2L 1L EE M6x10 mm Screw EE x6 Repeat steps 1 through 3 for the right legs (5R and 6R), right side panel (7) and drawer slide panel right (9R). 4. Feed the power cord from the power strip portion of the right side panel (7) through the grommet in the right rear leg (5R). 8L 4 4 5R 7 9R 6R 4 5.
ASSEMBLY INSTRUCTIONS 6. Attach a bottom frame (11) to the front of the left and right rear legs (1L and 5R) using screws (AA). Ensure the holes on the bottom frame (11) are facing up. 6 Hardware Used AA M6x10 mm Screw x4 1L AA AA 11 5R 7. Attach the base panel (12) to the bottom frames (11) and side frames (4) using screws (AA). 7 Hardware Used AA M6x10 mm Screw x 12 AA 12 4 11 8. Attach the back panel (14) to the left rear leg (1L) and right rear leg (5R) using screws (AA).
ASSEMBLY INSTRUCTIONS 9. Loosely attach screws (AA) to the end of the intermediate slide support (10). Align the screws (AA) with the holes in the back panel (14), insert the screws (AA) into the holes and lower the intermediate slide support (10). Tighten the screws (AA). 9 AA 14 10 Hardware Used AA M6x10 mm Screw x4 10. Attach the upper panel (13) to the left front leg (2L) and right front leg (6R) using screws (AA). 10 AA Hardware Used AA M6x10 mm Screw x4 6R 13 2L 11.
ASSEMBLY INSTRUCTIONS 12 12. Hardware Used 4 Screw 13. Attach the small drawer front (18) to the left drawer side panel (15L) and right drawer side panel (16R) by inserting screws (BB) through the small drawer front (18) and into the side panels (15L and 16R).
ASSEMBLY INSTRUCTIONS 15. Attach the large drawer front (22) to the left drawer side 15 panel (15L) and right drawer side panel (16R) by inserting screws (BB) through the large drawer front (22) and into the side panels (15L and 16R).
ASSEMBLY INSTRUCTIONS 18. Insert the left storage cage side panel (23L) into the keyhole slot on the left side of the pegboard (28). Slide the left storage cage side panel (23L) down until it meets the storage cage bottom panel (31). 18 26R 23L Repeat this step for the right storage cage side panel (26R). 31 28 19. Secure the left and right storage cage side panels (23L and 26R) with screws (AA and BB). 19 23L 26R BB Hardware Used AA M6x10 mm Screw BB M4x6 mm Screw AA x6 20.
ASSEMBLY INSTRUCTIONS 21. Attach the pegboard (28) to the left rear leg (1L) and the right rear leg (5R) using screws (AA). 21 Hardware Used 28 AA M6x10 mm Screw AA x4 5R 1L 22. Attach the light support brackets (29) to the underside of the storage cage bottom panel (31) using screws (CC) packaged with the light support bracket (29). The light support bracket (29) is packed in the box with the light (30). 22 29 CC 29 29 30 Hardware Used CC M4x8 mm Screw 30 x2 23.
ASSEMBLY INSTRUCTIONS 23. Insert the hanging hooks (33) into the holes on the right side of the workbench. 24 33 DRAWER REMOVAL 1. Pull the drawer out of the workbench until the slides are fully extended. Push the release lever down on the right side of the drawer. 1 2. Pull the release lever up on the left side of the drawer. Holding both levers, pull the drawer out until the drawer releases from the drawer slides.
CARE AND MAINTENANCE Cleaning 1. Clean using a mild liquid soap, rinse with clean water and dry thoroughly. Do not clean with abrasive detergents. 2. Clean off water or other liquids spilled or splashed on the workbench immediately and dry the unit thoroughly. 3. Keep your workbench covered to protect it from dust and moisture that could potentially damage the unit. TROUBLESHOOTING PROBLEM The tools plugged into the power strip do not work. The light does not work.
3-YEAR LIMITED WARRANTY This item carries a 3-year warranty from the date of purchase against defective parts and workmanship. Warranty does not cover damage due to mishandling or abuse. This warranty gives you specific legal rights, and you may have other rights that vary from state to state.
