User's Manual

The following is an alphabetical master list of all tools that may be utilized during the installation of the
external interfaces:
3. Tools, materials, and prerequisites – Required tools
● Crimping tools 22-16 gauge, 10-4/0 gauge (5-120 mm
2
) for installation of terminal lugs and c-taps
● Electrical conduit installation equipment and materials ● ESD wrist strap
● Eye protection gear — Safety goggles or glasses (R-3055)
●
Gloves
—L
ow
-
voltage
r
ubbe
r
l
in
e
m
a
n'
s gloves (R
-42
85)
G
gg(
)
● Heat gun for heat shrink tubing ● Insulated hand tools (for completing electrical connections)
● M10 eye bolts or hoisting rings ● Measuring tape
● Nut driver set (Imperial) with 10-inch extension ● Nut driver set (metric) with 250-mm extension
●
Ohmmeter (multi
meter volt/ohmmeter or equivalent)
●
Ohmmeter (multi
-
meter
,
volt/ohmmeter
,
or equivalent)
● Screwdrivers (power and manual), flat-blade, Phillips and Torx
● Small, regular, slip-joint pliers ● Tongue-and-groove, slip-joint pliers
● Socket sets (Imperial and metric) various drives, including 1/4" socket for security bit
● Stripping tool (for LDF4 antenna jumper cables) - part number 74Z-0-12-15 for Huber Suhner connectors;
- part number ITE-7189 for Andrew connectors.
● Tie wrap tool ● Torque wrenches, 2 - 34 N·m(17.7 - 300 lbf-in)
● Torque wrenches, 6 - 200 N·m (4.4 - 150 lbf-ft)
● Wire cutter [capable of cutting up to 50 mm
2
(1/0 AWG)] ● Wire stripper
● Wrench — Adjustable, (20 mm / 3/4 inch) open-end wrench (or set of fixed open-end wrenches)
- If fixed open end wrenches are used, both metric (mm) and Imperial system (in) wrenches will be
needed.
