Product Manual

30in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER’S MANUAL
8 of 10
Parts List Troubleshooting
Replacement Parts
• For replacement parts and technical questions, please call Customer Service at
1-800-222-5381.
• Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
• When ordering parts, the following will be required: model number, serial number/lot date
code, and description.
• The distributor reserves the rights to make design changes and or improvements to product
lines and manuals without notice.
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser
only ("You'' or “Your”) that the Klutch product purchased will be free from material defects in
both materials and workmanship, normal wear and tear excepted, for a period of one year from
date of purchase. The foregoing warranty is valid only if the installation and use of the product
is strictly in accordance with product instructions. There are no other warranties, express or
implied, including the warranty of merchantability or fitness for a particular purpose. If the
product does not comply with this limited warranty, Your sole and exclusive remedy is that We
will, at our sole option and within a commercially reasonable time, either replace the product or
product component without charge to You or refund the purchase price (less shipping). This
limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse,
neglect, misuse, or as a result of any accident or in any other manner; (c) damage from
misapplication, overloading, or improper installation; (d) improper maintenance and repair; and
(e) product alteration in any manner by anyone other than Us, with the sole exception of
alterations made pursuant to product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the
original purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the
product by make and model number, and follow the claim instructions that will be provided. The
product and the purchase receipt must be provided to Us in order to process Your warranty
claim. Any returned product that is replaced or refunded by Us becomes our property. You will
be responsible for return shipping costs or costs related to Your return visit to a retail store.
Part No.
1
2
3
4
5
6
7
8
9
10
11
42339
42340
42341
42342
42343
42344
13
14
15
16
17
18
19
20
21
22
23
24
25
27
28
29
Description
LEFT WALL
WORK BENCH
CROSSBEAM
CRANK ARM
RIGHT WALL
REAR FRAME
COVER
PRESS PLATE BRACKET
SPRING
PRESSING PLATE
MOVING CUTTER PLATE
UPPER BREAKING DIE 10"
UPPER BREAKING DIE 8"
UPPER BREAKING DIE 6"
UPPER BREAKING DIE 3"
UPPER BREAKING DIE 2"
UPPER BREAKING DIE 1"
DIE CLAMPING PLATE
HEX BOLT M8-1.25 X 40
ARM ROLLING WHEEL
POSITIONER
ADJUSTABLE BOLT
HANDLE ARM
THREADED ROD
POSITIONING PIECE
POSITIONING PLATE
SUPPORTING PLATE
CUTTER
BACK PRESSING ROLL
LOCK SCREW
ADJUSTABLE BOLT
BUSHING
PRESS COVER
Part No.
30
31
32
33
34
35
38
39
40
41
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
73
85
86
89
Description
GEAR
LOWER PRESSING ROLL
UPPER PRESSING ROLL
PROTECTING COVER
ROTATION SHAFT
ECCENTRIC SHAFT
KEY 6 X 6 X 20
CAP SCREW M6-1.0 X 16
CAP SCREW M6-1.0 X 8
HEX BOLT M6-1.0 X 44
KNOB
CAP SCREW M6-1.0 X 8
HEX BOLT M8-1.25 X 40
FLAT WASHER 8MM
HEX BOLT M8-1.25 X 40
HEX BOLT M8-1.25 X 24
FLAT WASHER 8MM
HEX NUT M8-1.25
HEX BOLT M10-1.5 X 16
CAP SCREW M8-1.25 X 30
CAP SCREW M6-1.0 X 24
CAP SCREW M8-1.25 X 16
FLAT WASHER 8MM
HEX BOLT M6-1.0 X 45
CAP SCREW M6-1.0 X 10
CAP SCREW M6-1.0 X 10
CAP SCREW M6-1.0 X 10
CAP SCREW M8-1.25 X 20
HANDLE ADJUST KNOB
PIN
GREASE FITTING 5⁄16"X1⁄4"
HEX NUT 10MM
Problem
Handle will not rotate 360 degrees
Probable Cuase
Upper shear blade bar may be
loose.
The male and female die may be
adjusted too dose or on object
between the male and female
dies. This may be preventing
rotation of the handle.
Top rolls may be locked by
over-tightening adjustment
knobs.
The lower table may be set too
close to plane of the nipper
shear blade.
Solution
Tighten bar locking screws firmly.
Over tightening will cause stiff
operation.
Readjust the male and female die.
Readjust the knobs.
Reset the table to the proper
position.
30in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER’S MANUAL
9 of 10
