Product Manual

30in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER’S MANUAL
30in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER’S MANUAL
Important Safety Information
WARNING:
• Read and understand all instructions. Failure to follow all instructions may result in serious
injury or property damage.
• The warnings, cautions, and instructions in this manual cannot cover all possible conditions
or situations that could occur. Exercise common sense and caution when using this tool.
Always be aware of the environment and ensure that the tool is used in a safe and
responsible manner.
• Do not allow persons to operate or assemble the product until they have read this manual
and have developed a thorough understanding of how it works.
• Do not modify this product in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the product. There are specific applications for
which the product was designed.
• Use the right tool for the job. DO NOT attempt to force small equipment to do the work of
larger industrial equipment. There are certain applications for which this equipment was
designed. It will do the job better and more safely at the capacity for which it was intended.
DO NOT use this equipment for a purpose for which it was not intended.
• Industrial or commercial applications must follow OSHA requirements.
WARNING:
• This product may contain chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
WORK AREA SAFETY
• Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well lit.
Cluttered, wet, or dark work areas can result in injury. Using the tool in confined work areas
may put you dangerously close to other cutting tools and rotating parts.
• Do not use the tool where there is a risk of causing a fire or an explosion; e.g., in the
presence of flammable liquids, gases, or dust. The tool can create sparks, which may ignite
the dust or fumes.
• Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the tool.
• Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in
your work area. Some of these hazards may be below the work surface hidden from your
view and may cause personal harm or property damage if unintentionally contacted.
PERSONAL SAFETY
• Stay alert, watch what you are doing, and use common sense when operating the tool. Do
not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A
moment of inattention while operating the tool may result in serious personal injury.
• Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts. Air vents on the tool often cover moving parts and should be
avoided.
• Use ANSI-Z87.1 compliant safety goggles or safety glasses with side shields, or when
needed, a face shield. Use a dust mask in dusty work conditions. Also use non-skid safety
shoes, hardhat, gloves, dust collection systems, and hearing protection when appropriate.
• Do not overreach. Keep proper footing and balance at all times.
• Secure the work with clamps or a vise instead of your hand when practical. This safety
precaution allows for proper tool operation using both hands.
CAUTION:
PRODUCT USE AND CARE
• Do not force the tool. Tools do a better and safer job when used in the manner for which they
are designed. Plan your work, and use the correct tool for the job.
• Check for damaged parts before each use. Carefully check that the tool will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never
operate the tool with a damaged part.
• Store the tool when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
• Use only accessories that are recommended by the manufacturer for use with your tool.
Accessories that may be suitable for one tool may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure
than the tool itself.
• Keep guards in place and in working order. Never operate the product without the guards in
place.
• Do not leave the tool running unattended.
Specific Operation Warnings
WARNING:
• Cut hazard. Keep fingers clear of the area in front and rear of the shear blades.
• Pinch point hazard. Keep hands clear of roller.
• Do not exceed the maximum shear capacity of 20 gauge mild steel.
Assembly
Unpack the sheet metal machine and check that all parts are present. If any parts are missing,
call the distributor at the number in the Replacement Parts section of this manual. When
unpacking, remove the bolts that are used to mount the machine to the crate. Save these bolts
for use when mounting to a stand or workbench.
Select a sturdy stand or workbench (not included), preferably a heavy-duty steel stand, and
locate the machine so the operating handle will swing clear of the end of the stand. Securely
bolt the machine to stand using 1-1/8" long hex head bolt with washers and nuts (not included).
Position the machine clear of obstructions to permit access to all sides. The floor around the
machine should be clean, and free of scraps, oil or grease. A suitable nonskid material should
be applied to the floor around the work station.
Note: The handle assembly (18) is shipped mounted to the right side of the machine. If you wish
to move the handle to the left side of the machine, proceed with the following instruction.
1. Loosen the handle adjustment knob (73) and slide the handle assemblye9e
2. Slide the handle assembly onto the opposite side and tighten the adjustment knob.
3. The handle assembly can be positioned in the eccentric bushing (20) as desired for
appropriate torque.
Install the back gauge assembly(19, 20, 21, 43) in either the shear (the angle iron points down)
or the press brake (the angle iron point up) position.
Lock the threaded rods (19) with the knob (43), provided in front in the shear position, in back in
the brake position.
The sheet metal machine is coated at the factory with a rust inhibitor. To ensure proper fit and
operation, remove the coating before first use. The coating is easily removed with a mild
solvent, such as mineral spirits, and a soft cloth.
Then, the parts of this machine which are ground, such as the rolls, should be coated with a
light film of oil to inhibit rust.
