8
MDC 1200 SYSTEM OPERATION
8-7
Transmitting a call
D Transmitting an MDC Message call
You can send a MDC Message call� There are 16
kinds of Messages�
(Menu > Signaling/Call > Message)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select “Signaling/
Call,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select
“Message,” then
push [OK]�
INDIV Select ►
Message ►
Signaling/Call
4� Push [P2 (Up)] or [P1 (Down)] to select a
Message, push [PTT] transmit an MDC Message
call�
✔ MSG 1
✔ MSG 2
Message
• “Success” is displayed when an acknowledgment is
received from the targeted station�
• “Failed” is displayed if an acknowledgment is not
received from the targeted station�
TIP:
• Push [Message] to directly display the “Message”
screen in step 4 above�
• Hold down [Message] for 1 second to transmit
the preset Message that is set in the “Message”
screen�
