7
NXDN™ OPERATION
7-11
D Transmitting an Emergency call
An NXDN Emergency call can be transmitted in
the same way as the 2-Tone, 5-Tone, or MDC 1200
signaling operation� See “Emergency call” for details�
(pp� 4-3 ~ 4-6)
Transmitting a call
D Transmitting Position data
When the GPS function is ON, and the optional
HM-233GP gps speaker microphone receives
Position data, the longitude and latitude data can be
automatically transmitted:
• When a GPS request status message is received�
• After sending a voice message�
L Set the Send with Login and Send with Logoff to
“Enable�”
• After sending a Status Message�
L Set the Send with Status Call to “Enable�”
• After sending a Message�
L Set the Send with Message Call to “Enable�”
• After sending a Call Alert�
L Set the Send with Call Alert to “Enable�”
• After sending an Emergency call�
L Set the Send with Emergency to “Enable�”
• At the preset interval�
L Set the Auto to “Enable�”
L Set the Interval Timer [mm:ss]�
NOTE: To transmit position data, the settings above
are required using the CS-F52D programming
software.
• (GPS > Digital)
• ( GPS > Common > Auto-Timed GPS Send)
