Operation Manual

3
BASIC OPERATION
3-5
D Rewriting the Priority A or B channel
(Menu > Channel/Scan > Prio A (RW))
(Menu > Channel/Scan > Prio B (RW))
1� Select a channel to be set as the Priority A or B
channel. (p. 3-4)
2� Push [Menu] to display the “Menu” screen.
3� Push [P2 (Up)] or [P1 (Down)] to select “Channel/
Scan,” then push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
4� Push [P2 (Up)] or [P1 (Down)] to select “Prio A
(RW)” or “Prio B (RW)” and push [OK].
Priority A CH ►
Prio A (RW) ►
Channel/Scan
5� After a dialog is displayed, as shown below, push
[P2 (Up)] or [P1 (Down)] to select <OK> on the
dialog, then push [OK].
R Are u Sure?
Cancel
OK
Prio A (RW)
• “Prio A (RW)” is briey displayed.
• Sets the selected channel as the Priority A or B
channel�
6� Hold down [Back] for 1 second to return to the
standby screen�
TIP: Hold down [Prio A (Rewrite)] or
[Prio B (Rewrite)] for 1 second to set the currently
selected channel as the Priority A or B channel�
D Selecting a Continuous tone channel
(Menu > Channel/Scan > C.Tone CH Sel)
1� While in the Analog mode, push [Menu] to display
the “Menu” screen.
2� Push [P2 (Up)] or [P1 (Down)] to select “Channel/
Scan,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “C.Tone
CH Sel,” then push [OK]�
C.Tone CH Sel ►
Compander ►
Channel/Scan
4� Push [P2 (Up)] or [P1 (Down)] to select a
Continuous tone channel, then push [OK].
✔ 1
✔ 2
C�Tone CH Sel
C.Tone CH Sel
2
• The selected Continuous tone channel is briey
displayed and set�
5� Hold down [Back] for 1 second to return to the
standby screen�
TIP: While in the Analog mode, push
[C�Tone CH Select] to directly display the “C�Tone
CH Sel” screen in step 4 above�
Selecting a channel (Continued)
