Datasheet

SPEC NO: DSAE7178 REV NO: V.4 DATE: NOV/17/2005 PAGE: 2 OF 3
APPROVED: J. Lu CHECKED: Allen Liu DRAWN: W.J.ZHU
Selection Guide
Note:
1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Part No. Dice Lens Type
Iv (mcd)
@ 10mA
Viewing
Angle
Min. Typ.
2 θ
θ θ
θ 1/2
L-710A8EW/1ID HIGH EFFICIENCY RED (GaAsP/GaP) RED DIFFUSED 12 25
40°
Electrical / Optical Characteristics at TA=25°C
Absolute Maximum Ratings at T
A=25°C
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
Symbol Parameter Device Typ. Max. Test ConditionsUnits
λpeak
Peak Wavelength High Efficiency Red 627 nm IF=20mA
λD
Dominant Wavelength High Efficiency Red 625 nm IF=20mA
∆λ1/2
Spectral Line Half-width High Efficiency Red 45 nm IF=20mA
C Capacitance High Efficiency Red 15 pF VF=0V;f=1MHz
VF Forward Voltage High Efficiency Red 2.0 2.5 V IF=20mA
IR Reverse Current High Efficiency Red 10 uA VR = 5V
Parameter High Efficiency Red Units
Power dissipation 105 mW
DC Forward Current 30 mA
Peak Forward Current [1] 160 mA
Reverse Voltage 5 V
Operating/Storage Temperature -40°C To +85°C
Lead Solder Temperature [2] 260°C For 3 Seconds
Lead Solder Temperature [3] 260°C For 5 Seconds
