K-90-5170
FM-200
®
Component Description
Safety Outlets
FEATURES
• For Use with UL Listed, ULC Listed and
FM Approved Systems
• See Kidde
®
Manual 90-FM200M-021 for
USCG Approval
MATERIALS
• Body and Retaining Nut: Brass
• Seal Wire: Copper and Lead
BODY
SEAL WIRE
SAFETY DISC
RETAINING NUT
NPT MALE
1.78"
(45mm)
3"
4
PART
NUMBER
AGENT
PRESSURE RELIEF
OPERATES AT
PSI BAR
803242
2400-2800 166-193
844346
FM-200
750-900 52-62
N 2/CO 2
FM-200 is a registered trademark of the Great Lakes Chemical Corporation.
