5
H1
I1
H2
I2
H1. Using a panel removal tool, remove the two (2) push pins holding lower center panel cover located on the passenger side. Slide cover off.
I1. Take out the rear center console pocket by using a panel
removal tool and remove the two (2) push pins.
I2. Once pins have been removed, pull up the pocket carefully.
Disconnect the harness attached to the 12v accessory socket.
PANELS AND DASH DISASSEMBLY
G1 G2 G3
G. Use a panel removal tool to remove the center dash panel and center pocket. Disconnect all harness connectors attached to the center dash panel.
