4-23
- IV Series User's Manual (Monitor) -
4
Check the image displayed on the monitor
and tap the [Register] button.
The conrmation dialog appears.
If the imaging area of the loaded image is
different, the conrmation dialog appears. If an
area that has not been imaged is registered,
the area will be displayed in black.
5
Tap the [OK] button.
The new master image will be registered and
returns to the main screen for the Master
Registration.
Register Live Image as Master Extended functions
1. Image Optimization 2. Master Registration 3. Tool Settings 4. Output Assignment
4
Settings Navigator (Setting the Judgment Condition)
