4-6
- IV Series User's Manual (Monitor) -
1. Image Optimization 2. Master Registration 3. Tool Settings 4. Output Assignment
Setting the Image Optimization
In this section, set the Image Optimization for taking an image of a target. Adjust the image for dening
differences in high and low-quality-targets.
Trigger Options
A trigger in this manual indicates the timing to start imaging with the built-in camera of the sensor. In the
Trigger Options, set the timing to image a target within the eld of view of this device. This device can
image a target at any timing and can image continuously.
“Setting the Trigger Options” (Page 4-8)
“Checking the view and installed distance” (Page 2-2)
Auto Brightness Adjustment
The sensor images a target by receiving the reected light of the built-in light exposed to a target using
the CMOS image sensor.
In the Auto Brightness Adjustment, a target can be imaged with an appropriate brightness by
automatically adjusting the light intensity and shutter speed according to the shape and surface
condition (color, shininess, material).
“Auto Brightness Adjustment” (Page 4-11)
Focus Adjustment
Adjusts the focus of lens. Adjusts for clearly imaging the shape of a target. Auto focus can adjust the
focusing position automatically.
“Focus Adjustment” (Page 4-12)
1. Image Optimization
(Clearly Image a Target)
4
Settings Navigator (Setting the Judgment Condition)
