4-4
- IV Series User's Manual (Monitor) -
Basic Operation of the Settings Navigator
Settings Navigator screen and operation ow
This section explains each setting screen to be displayed in the Settings Navigator and the operation ow.
For details of the contents that can set on each setting screen and its operation, refer to the applicable
references.
2. Master Registration
“2. Master Registration
(Registering an Image as a
Reference for Judgment)”
(Page 4-20)
1. Image Optimization
“1. Image Optimization
(Clearly Image a Target)”
(Page 4-6)
3. Tool Settings
“3. Tool Settings (Setting the
Judgment Method for Targets)”
(Page 4-28)
4. Output Assignment
“4. Output Assignment
(Setting Details of Outputting
to Output Line)” (Page 4-60)
A
A
A
A
A
4
Settings Navigator (Setting the Judgment Condition)
