3-3
- IV Series User's Manual (Monitor) -
Overview of Screen and Operation
A B
Sensor Setup Menu
Sets condition to judge a target.
“Displaying the Sensor Setup
Menu Screen” (Page 6-7)
Program list
Checks or initializes
the program.
“Things can be performed
with the program functions”
(Page 6-8)
Settings Navigator
Sets the program to be used
for judgment.
“Chapter 4 Settings Navigator
(Setting the Judgment Condition)”
(Page 4-1)
Limit Adjustment
Adjusts the judgment threshold.
“Adjusting Thresholds for
Judgment” (Page 5-14)
Tool Auto Tuning
Automatically adjusts threshold of
tool and extraction conditions of
Color Area/Area tool in accordance
with OK/NG image.
“Tool Auto Tuning (Automatically
Adjusting the Judgment
Condition)” (Page 5-15)
Sensor Advanced
Performs the sensor advanced settings.
“Setting the Extended Functions of
the Sensor” (Page 6-25)
A
Sensor Image History
Operates the sensor image history.
“Sensor Image History (Conrming the
Images whose Status Result is NG)”
(Page 6-14)
B
USB Memory
Sets the operation when using USB memory.
“Saving the Sensor Settings and Images
to a USB Memory” (Page 6-18)
3
Basic Operation
