Cables
Wiring
color
Name
Assigning
default value
Description
Brown DC24V - + side of power
Blue 0V -
- side of power
GND of input-output cable
Black OUT1 Total Status (N.O.)
Output assignable function
Total Status
Tot. StatusNG
RUN
BUSY
Error
Pos. Adj.
Judge result of each tool (Tool 1 to Tool 16)
Logical operation result of each tool (Tool 1 to Tool 4)
OFF (not used)
White OUT2 BUSY (N.O.)
Gray OUT3 Error (N.O.)
Orange OUT4 OFF
Pink IN1 External trigger ↑
Set external trigger.
Rising timing (↑) or falling timing (↓) can be set.
Yellow IN2 OFF
Input assignable function
Program bit0 to bit4
Clear Error
Ext. Master Save
OFF (not used)
Light Blue IN3 OFF
Purple IN4 OFF
Green IN5 OFF
Red IN6 OFF
Drain FG - Insulated frame
Cable specication
Brown/Blue/Black/White/Gray/Orange : AWG25
Pink/Yellow/Light Blue/Purple/Green/Red : AWG28
With braided shield cable (with drain cable)
The output cable assignment can be changed.
“4. Output Assignment (Setting Details of Outputting to Output Line)” (Page 4-60)
N.O./N.C. can be changed.
“Output Settings” (Page 6-27)
The input cable assignment can be changed.
“Input Settings” (Page 6-26)
Individually insulate the non-used input-output cables.
For input cables of this sensor, connect with non-contact output (transistor output/SSR output).
For contact output (relay output), incorrect input may be operated due to the contact bouncing.
