Remedy when the Monitor cannot be Connected with the Sensor
Remedy when data transfer via FTP is unavailable
Status Remedy
Connection with the FTP server failed.
Conrm the IP address of the FTP server and set it
correctly.
Conrm the port number of the FTP server and set it
correctly. Moreover, conrm the rewall software on the
PC whether the port is available or not.
Conrm the user name for logging in to the FTP server
and set it correctly.
Conrm the password for logging in to the FTP server
and set it correctly.
“FTP Destination Settings” (Page 6-33)
Data transfer to the transfer destination
folder failed.
Authorization for accessing the transfer destination folder
is not granted. Acquire the access authorization of the
transfer destination folder and perform the operation
again.
Conrm that there is no le with the same name as the
transfer destination folder name which has been set. If a
le with the same name exists, change the le name or
change the transfer destination folder.
“Transfer Destination Folder Settings” (Page 6-35)
When you switched from the [Run] screen to the
[Program] screen, the screen is switched to the [Program]
screen after the transfer of untransferred data has
nished.
If you click the [Cancel] button during the transfer, the
transfer will be forcibly nished and the Error screen will
appear.
