A-27
- IV Series User's Manual (Monitor) -
A
Error Messages
Message Cause Remedy
Output/
Indicator
This le conguration data is for
xxxx.
This le is not readable.
The setting les for a
different model of sensors
cannot be read.
Read the setting les of a sensor
of the same model.
FTP Connection Error Connection with the FTP
server failed.
Refer to
“Remedy when data
transfer via FTP is unavailable”
(Page A-38).
*2
FTP Transfer Error
(Transfer Failed)
Data transfer to the
transfer destination folder
failed.
FTP Transfer Error
(Insufcient Data Buffer)
Data which is larger than
the remaining storage of
the FTP buffer has been
created and the transfer
failed.
*1 Error output from the sensor: ON, PWR/ERR indicator light of the sensor: Lighting (red),
PWR indicator light of the monitor: Lighting (red)
*2 Error output from the sensor: ON, PWR/ERR indicator light of the sensor: Blinking (red),
PWR indicator light of the monitor: Blinking (red)
*3 PWR indicator light of the monitor: Lighting (red)
*4 SENSOR indicator light of the monitor: Off
